Galvanized Wire

Galvanized Wire Types: Long-Lasting and Versatile Solutions

Galvanized wire, PVC-coated wire, and black wire products offer solutions for various industries. Thanks to their high tensile strength and corrosion-resistant coating, they provide long-lasting use. They are a reliable choice for agriculture, construction, and landscaping projects.

While offering an aesthetic appearance with various coating and color options, their durable structure also meets security and protection needs.



Technical Specifications
Product Hot-Dip Galvanized Wire
Raw Material Standard TS EN 10244-2
Raw Material SAE 1006, SAE 1008, SAE 1010, SAE 1018, SAE 1030
Coating Method Hot-Dip Galvanized Wire
Wire Diameter 0.50mm - 5.50mm
Coating Amount 35gr/m² - 300gr/m²
Tensile Strength 350N/mm² - 1000N/mm²
Coil Weight 50kg - 1000kg
Coil Inner Diameter 350mm - 450mm
Coil Outer Diameter 540mm - 730mm
Packaging Steel Ring at 4 Points, Cardboard Separator at 8 Points, Steel Strip at 4 Points, Rosette Wound Coil





Product PVC Coated Wire
Raw Material Standard SAE 1006, SAE 1008, SAE 1010, SAE 1018, SAE 1030, TS EN 10244-2, BS443, DIN 1548, ASTM A475
Material Hot-Dip Galvanized Wire
Coating Method Extrusion
Coating Thickness 1mm
Wire Diameter 2.5mm - 4.5mm
Color Available in Desired Colors
Tensile Strength min. 350N/mm²
Coil Weight 50kg - 1000kg
Coil Inner Diameter 350mm - 450mm
Coil Outer Diameter 540mm - 730mm
Packaging Steel Ring at 4 Points, Cardboard Separator at 8 Points, Steel Strip at 4 Points, Rosette Wound Coil





Product Black Wire - Super Bright Wire
Raw Material Standard SAE 1006, SAE 1008, SAE 1010
Wire Diameter 1.25mm - 5.00mm
Tensile Strength 600N/mm² - 1000N/mm²
Coil Inner Diameter 45cm
Barb Spacing 13 - 20kg
Coil Weight 50kg - 500kg
General Features
  • Offers high-strength galvanized and PVC-coated wire options.
  • Long-lasting with its corrosion-resistant structure.
  • Provides aesthetic solutions with various color and coating options.

Areas of Use

  • Environmental protection and support in agricultural areas
  • Security fences in industrial zones
  • Decorative applications in landscaping arrangements
  • Structural reinforcement projects in the construction sector
